Maps SDK for JavaScript
Back to all examples
Add Stops to Route
Dynamically add and remove intermediate stops on a route by clicking the map
import type { Route, Waypoint, WaypointLike } from '@tomtom-org/maps-sdk/core'; import { bboxFromGeoJSON, TomTomConfig, withInsertedWaypoint } from '@tomtom-org/maps-sdk/core'; import type { WaypointDisplayProps } from '@tomtom-org/maps-sdk/map'; import { BaseMapModule, MIDDLE_INDEX, RoutingModule, TomTomMap } from '@tomtom-org/maps-sdk/map'; import { calculateRoute, geocodeOne } from '@tomtom-org/maps-sdk/services'; import { LngLat, Popup } from 'maplibre-gl'; import { API_KEY } from './config'; import './style.css'; import { initTogglePanel } from './togglePanel'; // (Set your own API key when working in your own environment) TomTomConfig.instance.put({ apiKey: API_KEY }); (async () => { const [origin, destination] = await Promise.all([geocodeOne('Washington'), geocodeOne('New York')]); const map = new TomTomMap({ mapLibre: { container: 'sdk-map', bounds: bboxFromGeoJSON([origin, destination]), fitBoundsOptions: { padding: 50 }, }, }); const [routingModule, baseModule] = await Promise.all([RoutingModule.get(map), BaseMapModule.get(map)]); // --- State --- let stops: [number, number][] = []; let currentRoute: Route; let activePopup: Popup | null = null; let isUpdating = false; // --- Helpers --- const getLocations = (): WaypointLike[] => [origin, ...stops, destination]; const closeActivePopup = () => { activePopup?.remove(); activePopup = null; }; const setLoading = (loading: boolean) => { isUpdating = loading; map.mapLibreMap.getCanvas().style.cursor = loading ? 'wait' : ''; }; const recalculate = async () => { const routeResult = await calculateRoute({ locations: getLocations() }); currentRoute = routeResult.features[0]; routingModule.showWaypoints(getLocations()); routingModule.showRoutes(routeResult); }; const addStop = async (pos: [number, number]) => { if (isUpdating) return; setLoading(true); try { const updated = withInsertedWaypoint(currentRoute, getLocations(), pos); stops = updated.slice(1, -1) as [number, number][]; await recalculate(); } finally { setLoading(false); } }; const removeStop = async (index: number) => { if (isUpdating) return; setLoading(true); try { stops = stops.filter((_, i) => i !== index); await recalculate(); } finally { setLoading(false); } }; // --- Initial route --- const initialResult = await calculateRoute({ locations: [origin, destination] }); currentRoute = initialResult.features[0]; routingModule.showWaypoints([origin, destination]); routingModule.showRoutes(initialResult); // --- Waypoint click: show "Remove stop" popup for intermediate stops --- routingModule.events.waypoints.on('click', (waypoint: Waypoint<WaypointDisplayProps>, lngLat: LngLat) => { if (waypoint.properties.indexType !== MIDDLE_INDEX || isUpdating) return; closeActivePopup(); // waypoint.properties.index is its position in [origin, ...stops, destination], // so the corresponding index in the stops array is index - 1. const stopIndex = waypoint.properties.index - 1; const popup = new Popup({ closeButton: false, anchor: 'bottom', className: 'stop-action-popup', }) .setLngLat(lngLat) .setHTML( `<button class="sdk-example-button sdk-example-button-secondary stop-popup-btn">Remove stop</button>`, ) .addTo(map.mapLibreMap); activePopup = popup; popup .getElement() .querySelector('.stop-popup-btn') ?.addEventListener('click', () => { closeActivePopup(); removeStop(stopIndex); }); }); // --- Map click: show "Add Stop" popup (or dismiss existing popup) --- baseModule.events.on('click', (_: unknown, lngLat: LngLat) => { if (isUpdating) return; if (activePopup) { closeActivePopup(); return; } const popup = new Popup({ offset: 15, closeButton: false, anchor: 'bottom', className: 'stop-action-popup', }) .setLngLat(lngLat) .setHTML(`<button class="sdk-example-button stop-popup-btn">Add stop</button>`) .addTo(map.mapLibreMap); activePopup = popup; popup .getElement() .querySelector('.stop-popup-btn') ?.addEventListener('click', () => { closeActivePopup(); addStop(lngLat.toArray()); }); }); initTogglePanel(); })();
