Geometries playground

This example on GitHub

Display multiple geographic geometries with different configurations

Geometries playground
import type { BBox, Places } from '@tomtom-org/maps-sdk/core';
import { TomTomConfig } from '@tomtom-org/maps-sdk/core';
import {
    calculateFittingBBox,
    GeometriesModule,
    type GeometriesModuleConfig,
    type GeometryBeforeLayerConfig,
    type GeometryPaletteMode,
    geometriesKnobCatalogue,
    knobEntryOf,
    type StandardStyleID,
    standardStyleIDs,
    TomTomMap,
} from '@tomtom-org/maps-sdk/map';
import { geocode, geometryData } from '@tomtom-org/maps-sdk/services';
import type { LngLatBoundsLike } from 'maplibre-gl';
import type { Config } from './placeConfiguration';
import { namedConfigs, palettes } from './placeConfiguration';
import './style.css';
import { API_KEY } from './config';
import { initTogglePanel } from './togglePanel';

// (Set your own API key when working in your own environment)
TomTomConfig.instance.put({ apiKey: API_KEY, language: 'en-GB' });

const OWN_PALETTE = "The region's own";

(async () => {
    const map = new TomTomMap({
        mapLibre: {
            container: 'sdk-map',
        },
    });
    const geometryModule = await GeometriesModule.create(map);
    let placeSubdivisions: Places;
    let region: Config;

    // The palette mode select lists the knob's catalogue options, with its description as the tooltip.
    const paletteSelector = document.getElementById('ui-palette') as HTMLSelectElement;
    const paletteModeSelector = document.getElementById('ui-paletteMode') as HTMLSelectElement;
    const paletteModeKnob = knobEntryOf(geometriesKnobCatalogue, 'fill.paletteMode');
    [OWN_PALETTE, ...Object.keys(palettes)].forEach((name) => paletteSelector.add(new Option(name)));
    paletteModeKnob.options?.forEach((mode) => paletteModeSelector.add(new Option(mode)));
    paletteModeSelector.title = paletteModeKnob.description;

    // The region's fill, in the palette mode picked here. A palette picked here takes the place of the
    // region's own, and of its single `fill.color` too.
    const fillConfig = (): GeometriesModuleConfig['fill'] => {
        const fill = region.geometryConfig.fill;
        const palette = palettes[paletteSelector.value];
        const paletteMode = paletteModeSelector.value as GeometryPaletteMode;
        return palette ? { opacity: fill?.opacity, palette, paletteMode } : { ...fill, paletteMode };
    };
    const applyPalette = () => geometryModule.updateConfig({ fill: fillConfig() });

    const placeBBox = () =>
        calculateFittingBBox({
            map,
            toBeContainedBBox: placeSubdivisions.bbox as BBox,
            surroundingElements: ['#ui-panel'],
        }) as LngLatBoundsLike;

    const updateMap = async (config: Config) => {
        region = config;
        paletteSelector.value = OWN_PALETTE;
        paletteModeSelector.value = config.geometryConfig.fill?.paletteMode ?? String(paletteModeKnob.default);
        placeSubdivisions = await geocode({ limit: 100, query: '', ...config.searchConfig });
        map.mapLibreMap.fitBounds(placeBBox());
        const geometries = await geometryData({ geometries: placeSubdivisions, zoom: 14 });
        geometryModule.applyConfig({ ...config.geometryConfig, fill: fillConfig() });
        geometryModule.show(geometries);
    };

    const listenToUIEvents = async () => {
        const placeSelector = document.getElementById('ui-placeSelector') as HTMLSelectElement;
        placeSelector.addEventListener('change', (event) =>
            updateMap(namedConfigs[(event.target as HTMLInputElement).value]),
        );
        paletteSelector.addEventListener('change', applyPalette);
        paletteModeSelector.addEventListener('change', applyPalette);

        const options = document.querySelectorAll<HTMLInputElement>('input[type=radio][name=layerOption]');
        options.forEach((option) => {
            option.addEventListener('change', () =>
                geometryModule.updateConfig({ beforeLayerConfig: option.value as GeometryBeforeLayerConfig }),
            );
        });

        const stylesSelector = document.querySelector('#ui-mapStyles') as HTMLSelectElement;
        standardStyleIDs.forEach((id) => stylesSelector.add(new Option(id)));
        stylesSelector.addEventListener('change', (event) =>
            map.setStyle((event.target as HTMLOptionElement).value as StandardStyleID),
        );

        document
            .querySelector('#ui-reCenter')
            ?.addEventListener('click', () => placeSubdivisions && map.mapLibreMap.fitBounds(placeBBox()));
    };

    await updateMap(namedConfigs.france);
    await listenToUIEvents();

    initTogglePanel();
})();

Pick a region set and each subdivision comes back shaded from that set’s own colours. Swap in another palette, or switch the palette mode between taking the colours in turn and ramping through them. Pick a layer position and the set slides up or down the base map’s stack.

  • geometryData takes the geocode response itself as its input, and GeometriesModule.show draws the polygons it returns with no source or layer of your own.
  • applyConfig takes a list of CSS colours as fill.palette and hands them to the features in turn, so you never assign a colour per feature. With fill.paletteMode set to 'ramp', as Chicago’s postcodes start, they blend instead: two colours shade every postcode between them, and a middle colour is a stop the ramp passes through.
  • updateConfig with a beforeLayerConfig re-seats the geometry layers under roads, labels or buildings without re-fetching or re-showing anything.
