Find the nearest of your own stores by drive time, from any address.

Store locator
import {
    bboxFromGeoJSON,
    formatDistance,
    formatDuration,
    type Place,
    type Routes,
    TomTomConfig,
} from '@tomtom-org/maps-sdk/core';
import { PlacesModule, RoutingModule, TomTomMap } from '@tomtom-org/maps-sdk/map';
import { calculateRoute, createLatestRequest, geocode } from '@tomtom-org/maps-sdk/services';
import { API_KEY } from './config';
import { type Store, stores } from './stores';
import './style.css';

// (Set your own API key when working in your own environment)
TomTomConfig.instance.put({ apiKey: API_KEY, language: 'en-GB' });

const SHORTLIST_SIZE = 3;
const PADDING = { top: 100, bottom: 80, left: 80, right: 400 };

const searchForm = document.getElementById('ui-search') as HTMLFormElement;
const addressInput = document.getElementById('ui-address') as HTMLInputElement;
const statusText = document.getElementById('ui-status') as HTMLParagraphElement;
const storeList = document.getElementById('ui-stores') as HTMLOListElement;

// Only compared with each other, so a flat projection is close enough within one city.
const straightLineDistance = ([fromLng, fromLat]: number[], [toLng, toLat]: number[]) =>
    Math.hypot((toLng - fromLng) * Math.cos((fromLat * Math.PI) / 180), toLat - fromLat);

const summaryOf = (routes: Routes) => routes.features[0].properties.summary;
const storeByID = (id: string | undefined) => stores.features.find((store) => store.id === id);

(async () => {
    const map = new TomTomMap({
        mapLibre: { container: 'sdk-map', bounds: bboxFromGeoJSON(stores), fitBoundsOptions: { padding: PADDING } },
    });
    const routingModule = await RoutingModule.create(map);
    const placesModule = await PlacesModule.create<Store>(map, {
        color: '#b4530a',
        label: { title: (store) => store.properties.name },
    });
    await placesModule.show(stores);

    let visitor: Place;
    let ranked: { store: Place<Store>; routes: Routes }[] = [];
    let selectedID: string | undefined;

    const selectStore = async (store: Place<Store>) => {
        selectedID = store.id;
        placesModule.setEventState({ id: store.id, state: 'click' });
        for (const button of storeList.querySelectorAll('button')) {
            button.classList.toggle('ui-selected', button.dataset.storeId === store.id);
        }
        // A store off the shortlist has no route yet, so a click on its pin plans one.
        const routes =
            ranked.find((entry) => entry.store.id === store.id)?.routes ??
            (await calculateRoute({ locations: [visitor, store] }));
        if (selectedID === store.id) await routingModule.showRoutes(routes);
    };

    const lookUpNearestStores = async (address: string, signal: AbortSignal) => {
        const geoBias = { position: map.mapLibreMap.getCenter().toArray() };
        const [origin] = (await geocode({ query: address, limit: 1, geoBias, filters: { countries: ['NL'] }, signal }))
            .features;
        if (!origin) return undefined;

        const shortlist = [...stores.features]
            .sort(
                (first, second) =>
                    straightLineDistance(origin.geometry.coordinates, first.geometry.coordinates) -
                    straightLineDistance(origin.geometry.coordinates, second.geometry.coordinates),
            )
            .slice(0, SHORTLIST_SIZE);
        const routes = await Promise.all(
            shortlist.map((store) => calculateRoute({ locations: [origin, store], signal })),
        );
        return { origin, shortlist, routes };
    };

    // A newer search retires the one still in flight, so its late answer cannot repaint the list.
    const latestSearch = createLatestRequest();

    const findNearestStores = async (address: string) => {
        statusText.textContent = 'Finding your nearest stores…';
        const found = await latestSearch.run((signal) => lookUpNearestStores(address, signal));
        if (!found.current) return;
        if (!found.value) {
            statusText.textContent = `No address found for "${address}".`;
            return;
        }
        const { origin, shortlist, routes } = found.value;
        visitor = origin;

        const bounds = bboxFromGeoJSON(routes);
        if (bounds) map.mapLibreMap.fitBounds(bounds, { padding: PADDING, animate: false });
        ranked = shortlist
            .map((store, index) => ({ store, routes: routes[index] }))
            .sort(
                (first, second) =>
                    summaryOf(first.routes).travelTimeInSeconds - summaryOf(second.routes).travelTimeInSeconds,
            );

        storeList.innerHTML = ranked
            .map(({ store, routes }) => {
                const { travelTimeInSeconds, lengthInMeters } = summaryOf(routes);
                return `<li><button class="ui-store" data-store-id="${store.id}">
                    <span class="ui-store-name">${store.properties.name}</span>
                    <span class="ui-store-address">${store.properties.address.freeformAddress}</span>
                    <span class="ui-store-trip">${formatDuration(travelTimeInSeconds) ?? 'under 1 min'} · ${formatDistance(lengthInMeters)}</span>
                </button></li>`;
            })
            .join('');
        statusText.textContent = '';

        await routingModule.showWaypoints([origin]);
        await selectStore(ranked[0].store);
    };

    await findNearestStores(addressInput.value);

    searchForm.addEventListener('submit', (event) => {
        event.preventDefault();
        void findNearestStores(addressInput.value);
    });
    storeList.addEventListener('click', (event) => {
        const store = storeByID((event.target as HTMLElement).closest('button')?.dataset.storeId);
        if (store) void selectStore(store);
    });
    placesModule.events.places.on('click', (place) => {
        const store = storeByID(place.id);
        if (store) void selectStore(store);
    });
})();

A bakery chain’s own GeoJSON shows as pins, and the address you type lines up its three nearest stores in order of drive time, with the route to the one you pick.

  • PlacesModule.show takes the Places collection in stores.ts unchanged, as it would a search response, and label.title reads each store’s name.
  • calculateRoute takes the geocoded address and a store feature unchanged, so ranking the straight-line shortlist costs three calls and no conversion.
  • setEventState gives the store picked in the list the same pin look a click on the map gives it.
