3D terrain playground

This example on GitHub

A tilted satellite map over the Matterhorn, with terrain, sky and exaggeration that outlive a style switch

3D terrain playground
import { TomTomConfig } from '@tomtom-org/maps-sdk/core';
import {
    resetKnob,
    type StandardStyleID,
    StylingFoundationsModule,
    setKnob,
    standardStyleIDs,
    stylingFoundationsKnobCatalogue,
    type TerrainKnob,
    type TerrainKnobId,
    TerrainModule,
    TomTomMap,
    terrainKnobCatalogue,
} from '@tomtom-org/maps-sdk/map';
import { MapEffects } from '@tomtom-org/maps-sdk-plugin-map-effects';
import './style.css';
import { API_KEY } from './config';
import { initTogglePanel } from './togglePanel';

// (Set your own API key when working in your own environment)
TomTomConfig.instance.put({ apiKey: API_KEY, language: 'en-GB' });

// A camera aimed at the relief rather than at a place: the summit in the middle of the screen, the
// bearing of the valley it is usually photographed from.
type Viewpoint = {
    label: string;
    center: [number, number];
    zoom: number;
    bearing: number;
};

const viewpoints: Viewpoint[] = [
    { label: 'Matterhorn, Switzerland', center: [7.6586, 45.9763], zoom: 12.6, bearing: 178 },
    { label: 'Mont Blanc, France', center: [6.8652, 45.8326], zoom: 12.2, bearing: 320 },
    { label: 'Grand Canyon, United States', center: [-112.14, 36.1], zoom: 12.2, bearing: 0 },
    { label: 'Mount Fuji, Japan', center: [138.7274, 35.3606], zoom: 11.4, bearing: 172 },
];

const INITIAL_PITCH = 72;
const INITIAL_EXAGGERATION = 1.4;

const terrainKnob = (id: TerrainKnobId): TerrainKnob => {
    const entry = terrainKnobCatalogue.find((candidate) => candidate.id === id);
    if (!entry) throw new Error(`No terrain knob '${id}'`);
    return entry;
};

// The satellite basemap is a daylit photograph, but its dark labels put the style in the dark
// theme, whose night sky sits oddly above sunlit rock. Every other style keeps the sky its own
// theme picks.
const DAYLIGHT_SKY_COLOR = '#88c6fc';
const DAYLIGHT_HORIZON_COLOR = '#ffffff';

// What the focus knob is choosing, since the number itself means nothing: the scale is distance
// across whatever the frame shows, so only its ends can be named exactly.
const focusLabel = (focus: number) => {
    if (focus <= 0) return 'Nearest';
    if (focus >= 1) return 'Farthest';

    return focus < 0.5 ? 'Near' : 'Far';
};

(async () => {
    const [initialViewpoint] = viewpoints;

    const map = new TomTomMap({
        style: 'streetSatellite',
        mapLibre: {
            container: 'sdk-map',
            center: initialViewpoint.center,
            zoom: initialViewpoint.zoom,
            bearing: initialViewpoint.bearing,
            pitch: INITIAL_PITCH,
            // MapLibre stops at 60° by default, which is where terrain starts to read as relief.
            maxPitch: 85,
            // The depth of field reads the rendered map back as a texture, which MapLibre allows
            // only when asked.
            canvasContextAttributes: { preserveDrawingBuffer: true },
        },
    });

    const [styling, terrainModule] = await Promise.all([
        StylingFoundationsModule.get(map, { view: { sky: { visible: true } } }),
        // The hillshade shades the same elevation the surface is raised from, which keeps a slope
        // readable where the camera flattens it.
        TerrainModule.get(map, {
            elevation: { visible: true, exaggeration: INITIAL_EXAGGERATION },
            hillshade: { visible: true },
        }),
    ]);

    // The effects plugin works on the rendered pixels, so it needs nothing from the style and
    // survives every switch below.
    const effects = new MapEffects(map);

    const viewpointSelector = document.querySelector('#ui-viewpoint') as HTMLSelectElement;
    const styleSelector = document.querySelector('#ui-mapStyle') as HTMLSelectElement;
    const terrain = document.querySelector('#ui-terrain') as HTMLInputElement;
    const hillshade = document.querySelector('#ui-hillshade') as HTMLInputElement;
    const sky = document.querySelector('#ui-sky') as HTMLInputElement;
    const depthOfField = document.querySelector('#ui-depthOfField') as HTMLInputElement;
    const exaggeration = document.querySelector('#ui-exaggeration') as HTMLInputElement;
    const exaggerationValue = document.querySelector('#ui-exaggerationValue') as HTMLElement;
    const pitch = document.querySelector('#ui-pitch') as HTMLInputElement;
    const pitchValue = document.querySelector('#ui-pitchValue') as HTMLElement;
    const followPointer = document.querySelector('#ui-followPointer') as HTMLInputElement;
    const focus = document.querySelector('#ui-focus') as HTMLInputElement;
    const focusValue = document.querySelector('#ui-focusValue') as HTMLElement;
    const band = document.querySelector('#ui-band') as HTMLInputElement;
    const bandValue = document.querySelector('#ui-bandValue') as HTMLElement;
    const blur = document.querySelector('#ui-blur') as HTMLInputElement;
    const blurValue = document.querySelector('#ui-blurValue') as HTMLElement;

    // Every knob writes the whole effect, so the sliders are live before the toggle and keep their
    // meaning after it: off is simply an intensity of 0.
    const applyDepthOfField = () =>
        effects.updateConfig({
            depthOfField: {
                intensity: depthOfField.checked ? Number(blur.value) : 0,
                focus: Number(focus.value),
                band: Number(band.value),
            },
        });

    const applySkyOf = (styleId: StandardStyleID) => {
        if (styleId === 'streetSatellite') {
            setKnob(styling, stylingFoundationsKnobCatalogue, 'view.sky.color', DAYLIGHT_SKY_COLOR);
            setKnob(styling, stylingFoundationsKnobCatalogue, 'view.sky.horizonColor', DAYLIGHT_HORIZON_COLOR);
            return;
        }

        resetKnob(styling, stylingFoundationsKnobCatalogue, 'view.sky.color');
        resetKnob(styling, stylingFoundationsKnobCatalogue, 'view.sky.horizonColor');
    };

    // The terrain controls read their tooltips from the module's catalogue, and the exaggeration
    // slider its bounds and step, so the panel offers only values the module takes.
    const { range, description } = terrainKnob('elevation.exaggeration');
    if (range) {
        exaggeration.min = String(range.min);
        exaggeration.max = String(range.max);
        exaggeration.step = String(range.step ?? 'any');
    }
    exaggeration.title = description;
    exaggeration.value = String(INITIAL_EXAGGERATION);
    exaggerationValue.textContent = exaggeration.value;
    terrain.parentElement?.setAttribute('title', terrainKnob('elevation.visible').description);
    hillshade.parentElement?.setAttribute('title', terrainKnob('hillshade.visible').description);

    viewpoints.forEach((viewpoint, index) => viewpointSelector.add(new Option(viewpoint.label, String(index))));
    standardStyleIDs.forEach((styleId) => styleSelector.add(new Option(styleId)));
    styleSelector.value = 'streetSatellite';
    applySkyOf('streetSatellite');

    viewpointSelector.addEventListener('change', () => {
        const { center, zoom, bearing } = viewpoints[Number(viewpointSelector.value)];
        map.mapLibreMap.flyTo({ center, zoom, bearing, pitch: Number(pitch.value), duration: 4000 });
    });

    // The terrain, its exaggeration and the sky are module settings rather than camera state, so
    // they survive this switch: both modules re-apply them on top of every style the map loads.
    styleSelector.addEventListener('change', () => {
        const styleId = styleSelector.value as StandardStyleID;
        map.setStyle(styleId);
        applySkyOf(styleId);
    });

    terrain.addEventListener('change', () => terrainModule.setElevationVisible(terrain.checked));
    sky.addEventListener('change', () =>
        setKnob(styling, stylingFoundationsKnobCatalogue, 'view.sky.visible', sky.checked),
    );
    hillshade.addEventListener('change', () => terrainModule.setHillshadeVisible(hillshade.checked));

    depthOfField.addEventListener('change', applyDepthOfField);

    const showFocus = () => {
        focusValue.textContent = focusLabel(Number(focus.value));
        applyDepthOfField();
    };

    focus.addEventListener('input', showFocus);

    // Depth runs up the screen on a tilted map, and the focus knob is read across what the frame
    // shows — so the row the pointer is on *is* the distance to focus on, with no unprojection and
    // no elevation query. A tap gives a tablet the same thing a hover gives a mouse.
    const focusAtPointer = ({ point }: { point: { y: number } }) => {
        if (!followPointer.checked || !depthOfField.checked) return;

        const height = Math.max(map.mapLibreMap.getCanvas().clientHeight, 1);
        focus.value = String(Math.min(Math.max(1 - point.y / height, 0), 1));
        showFocus();
    };

    map.mapLibreMap.on('mousemove', focusAtPointer);
    map.mapLibreMap.on('click', focusAtPointer);
    followPointer.addEventListener('change', () => {
        focus.disabled = followPointer.checked;
    });

    band.addEventListener('input', () => {
        bandValue.textContent = Number(band.value) === 0 ? 'One plane' : `${Math.round(Number(band.value) * 100)}%`;
        applyDepthOfField();
    });

    blur.addEventListener('input', () => {
        blurValue.textContent = `${blur.value}px`;
        applyDepthOfField();
    });

    exaggeration.addEventListener('input', () => {
        exaggerationValue.textContent = exaggeration.value;
        setKnob(terrainModule, terrainKnobCatalogue, 'elevation.exaggeration', Number(exaggeration.value));
    });

    pitch.addEventListener('input', () => {
        pitchValue.textContent = `${pitch.value}°`;
        map.mapLibreMap.setPitch(Number(pitch.value));
    });

    initTogglePanel();
})();

The camera sits at 72° over the Matterhorn and the ridges stand up out of the map. Switch the style underneath it (satellite, dark, mono) and the terrain, the sky and the exaggeration are all still there.

  • TerrainModule.get raises the surface and shades it with the hillshade from the same elevation data. It re-applies both over whatever setStyle loads, so you have no elevation source to restore.
  • terrainKnobCatalogue gives the exaggeration slider its range and each terrain control its tooltip, so the panel offers only values the module takes.
  • StylingFoundationsModule.get does the same for the view.sky.visible knob, the sky above the tilted horizon.
  • The depth-of-field sliders come from the map effects plugin. The camera’s own pitch turns a chosen distance into a band of the view, so flattening the map ends the effect.
